AIR OPERATED OIL PUMP Mod.503 R=3:1 DELIVERY CAPACITY 25 l/min
ART: 020-0995-000
For standard drums of 180–220 l (shank length 940 mm) Viton seals. With threaded ring for drum connection
PDF DOWNLOAD MANUAL
ART: 020-0995-000
For standard drums of 180–220 l (shank length 940 mm) Viton seals. With threaded ring for drum connection
Details
These pumps are advised for the transfer of low- to medium-viscosity oil (SAE 15/130), similar fluids and antifreeze, for short- to medium-distance (40 – 50 m). The delivery capacity of a pump varies according to particular applications and combinations: the pressure of air supplied; viscosity and temperature of the fluid; dimensions of delivery hose; dimensions of connections and type of gun which is used. The operating pressure may vary between a minimum of 3 bar and a maximum of 8 bar. To optimize the performance and the time-life of the air-operated pumps we advise to use filtered and lubricated air
Data sheet
- Gross weight 5.7 kg
- Net weight 4.9 kg
- Compression ratio 3:1
- Air consumption 200 l/min
- Noise level 80 dB
- Shank diameter 42 mm
- Shank length 940 mm
- Working pressure 6-8 bar
- Air Inlet connection F 1/4” G
- Oil outlet connection M 1/2” G
- Oil delivery capacity 8 bar 25 l/min
- For drums with capacity of 180-220 l
